Universal Seal™ DGYF-500C Portable Induction Sealing Machine

Description

The Universal Seal™ DGYF-500C Electro-Magnetic Induction Sealing Machine is a compact and portable solution designed for efficient wad sealing of compatible bottles and containers. With a wide 20–130 mm sealing diameter, 600W power consumption, and an approximate production capacity of 8–10 pcs/min, it is suitable for small to medium-scale packaging operations.

The machine uses electromagnetic induction technology to heat the compatible induction wad positioned inside the bottle cap. When the correct wad, cap and container combination is used, the process creates a secure seal at the container opening, helping protect packaged products against leakage, moisture and external contamination.

Its manual operation and compact construction make the DGYF-500C convenient for businesses requiring flexible bottle-sealing operations. It is suitable for applications across the food & beverage, pharmaceutical, cosmetics, personal care, chemical and general packaging industries.

Key Features

20–130 mm Wide Sealing Range: Suitable for various compatible bottle and container sizes within the specified sealing diameter.

600W Power: Provides efficient electromagnetic induction heating for regular wad-sealing applications.

Portable & Compact Design: Lightweight and compact construction makes the machine easy to position and operate in different work areas.

Manual Operation: Straightforward manual operation makes it suitable for small and medium-scale packaging requirements.

Approx. 8–10 pcs/min Capacity: Provides practical sealing output depending on container size, wad type, operator speed and machine settings.

Electromagnetic Induction Technology: Uses non-contact electromagnetic induction to activate a compatible wad liner positioned inside the bottle cap.

Secure Wad Sealing: Helps provide a reliable seal for compatible bottles and containers when the correct cap and induction wad are used.

Applications

Food & Beverage Packaging: Suitable for compatible bottles and jars used for sauces, oils, beverages, powders and other packaged food products.

Pharmaceutical Packaging: Can be used for compatible medicine, healthcare and supplement containers requiring secure wad sealing.

Cosmetics & Personal Care: Suitable for compatible bottles and jars containing creams, lotions, oils and other personal-care products.

Chemical Packaging: Can be used for compatible containers containing selected chemical and industrial products where secure sealing is required.

General Packaging: Suitable for businesses requiring portable induction wad sealing for compatible bottles, jars and containers.

How to Use

Machine Preparation: Place the DGYF-500C on a stable, dry and level surface. Ensure that the induction sealing head and surrounding area are clean.

Prepare the Container: Fill the compatible bottle or container and place the appropriate induction sealing wad correctly inside the cap.

Close the Cap: Tighten the cap properly so that the wad is positioned evenly against the container opening.

Adjust the Settings: Set the appropriate sealing parameters according to the container size, cap material and wad specification.

Position the Sealing Head: Place the induction head correctly over the capped container. Ensure the container falls within the machine's 20–130 mm sealing range.

Start Sealing: Activate the machine to begin the electromagnetic induction process. The compatible wad liner is heated and bonded to the container opening.

Inspect the Seal: Allow the container to cool briefly and inspect the seal for proper adhesion before beginning bulk production.

Important Note

• This machine is not intended for direct aluminium foil sealing. It is designed for compatible induction wad sealing only.
• Always use the correct induction wad, cap and container combination.
• Sealing results depend on the wad specification, container material, cap design, sealing time and operating settings.
• A test seal should be performed before starting bulk production.
• Actual production capacity may vary depending on container size and operator speed.

Maintenance

Regular Cleaning: Keep the machine body and induction sealing head clean and free from dust, product residue and other contaminants.

Inspect the Induction Head: Regularly check the sealing head and connecting cable for visible wear or damage.

Electrical Safety Checks: Periodically inspect the power cable, plug and electrical connections for damage or loose connections.

Keep the Machine Dry: Protect the electrical components and induction head from excessive moisture.

Switch Off Before Maintenance: Always turn off and disconnect the machine from the power supply before cleaning, inspection or maintenance.

Brand: Universal Seal™

Model: DGYF-500C

Machine Type: Electro-Magnetic Induction Sealing Machine

Sealing Diameter: 20–130 mm

Power Consumption: 600W

Capacity: Approx. 8–10 pcs/min

Product Origin: Imported

Universal Seal™ | Since 2010

Universal Packaging Solutions, New Delhi
