Universal Seal™ LX6000 SS Electromagnetic Induction Sealing Machine – 20 to 80 mm

The Universal Seal™ LX6000 SS Electromagnetic Induction Sealing Machine is a heavy-duty packaging solution designed for reliable induction cap sealing of compatible non-metal bottles and containers. Built with a durable stainless steel (SS) body, the machine is suitable for regular commercial and industrial packaging operations.

With a sealing diameter range of 20–80 mm and support for bottle heights from 80–300 mm, the LX6000 SS can accommodate a variety of compatible bottle sizes. The electromagnetic induction system heats the compatible aluminium foil liner inside the bottle cap, helping create a secure seal that reduces leakage, provides tamper evidence and supports product freshness during storage and transportation.

The machine operates on a 220 V, 50 Hz power supply and features a 600 W rated power with 1200 W input power. Its air-cooling system supports stable operation, while the adjustable setup allows the machine to be configured according to different compatible bottle dimensions.

Key Features

• Stainless Steel (SS) body for durability and easy maintenance
• Electromagnetic induction sealing technology
• 20–80 mm sealing diameter range
• Suitable for bottle diameters from 20–80 mm
• Supports bottle heights from 80–300 mm
• 600 W rated power
• 1200 W input power
• Air-cooling system
• Simple and convenient operation
• Helps provide secure, leak-resistant and tamper-evident sealing
• Suitable for regular commercial and industrial packaging applications

Applications

The LX6000 SS Induction Sealing Machine can be used across various packaging industries, including:

• Food Industry: Suitable for sealing compatible food containers and bottles to help protect the packaged product from leakage and external contamination.
• Pharmaceuticals: Suitable for compatible medicine and pharmaceutical bottles where secure and tamper-evident packaging is required.
• Cosmetics: Can be used for compatible bottles containing creams, lotions, oils and other cosmetic products.
• Chemical & Lubricant Industry: Suitable for compatible containers requiring secure sealing during storage and transportation.
• Laboratory Applications: Can be used for compatible sample and laboratory containers where leakage prevention is important.

How to Use

1. Place the machine on a stable and level surface and connect it to a suitable 220 V, 50 Hz power supply.
2. Adjust the machine according to the height and size of the bottle being sealed.
3. Ensure the bottle opening and cap are clean and dry.
4. Place a compatible induction-sealing aluminium foil liner inside the bottle cap and tighten the cap correctly.
5. Switch on the machine and set the required operating parameters according to the bottle, cap and liner material.
6. Pass the prepared bottles through the sealing area for electromagnetic induction sealing.
7. After sealing, inspect the liner to ensure that a proper and uniform seal has been achieved.
8. Adjust the settings if required before starting continuous production.

Maintenance

• Regularly clean the stainless steel body and sealing area using a soft cloth.
• Keep the machine free from dust, packaging residue and other contaminants.
• Periodically inspect electrical connections, cables and controls for damage or loose connections.
• Ensure the air-cooling system remains clean and unobstructed.
• Check sealing performance regularly and adjust operating settings according to the bottle, cap and liner being used.
• Switch off and disconnect the machine from the power supply before cleaning or maintenance.

Technical Highlights

Model No.: LX6000 SS

Body Material: Stainless Steel (SS)

Sealing Diameter: 20–80 mm

Bottle Diameter: 20–80 mm

Bottle Height: 80–300 mm

Power: 600 W

Input Power: 1200 W

Power Supply: 220 V, 50 Hz

Weight: Approx. 26 kg

Country of Origin: China

Brand: Universal Seal™

Imported & Marketed By: Universal Packaging Solutions
