Universal Seal™ DGYF-600A Manual Induction Sealing Machine – 20 to 100 mm

Description

The Universal Seal™ DGYF-600A Manual Induction Sealing Machine is a compact and portable solution designed for sealing compatible wad-lined bottles, jars and containers. Using electromagnetic induction technology, the machine generates controlled heat to activate the compatible sealing wad inside the cap, helping create a secure seal between the container opening and liner.

With a sealing diameter range of 20–100 mm, 500W power and a capacity of up to 65 pcs/min depending on container size, operator handling and sealing settings, the DGYF-600A is suitable for small to medium-scale packaging operations. Its lightweight design and simple manual operation make it convenient for businesses requiring flexible bottle and jar sealing.

The machine can be used across food, pharmaceutical, cosmetic, chemical, lubricant and other compatible packaging applications.

Key Features & Benefits

20–100 mm Sealing Range

Suitable for compatible bottles, jars and containers with sealing diameters ranging from 20 mm to 100 mm.

500W Power

Equipped with a 500W induction system for efficient heating and sealing of compatible wad liners.

Manual & Portable Operation

Its compact design and approximate weight of 2.5 kg make the machine convenient to operate, handle and reposition as required.

Electromagnetic Induction Technology

Uses non-contact electromagnetic induction to heat the compatible wad liner while the container remains capped.

Up to 65 pcs/min Capacity

Offers a rated capacity of 0–65 pcs/min. Actual output depends on container size, wad material, sealing time and operator handling.

Adjustable Sealing Settings

Operating parameters can be adjusted according to the container, cap and compatible wad liner being used.

Secure Packaging

Proper sealing can help provide protection against leakage, moisture, contamination and tampering, depending on the container and wad combination.

Applications

Food & Beverage Packaging: Suitable for compatible bottles and jars used for sauces, oils, powders, spices and other packaged food products.

Pharmaceutical Packaging: Can be used for compatible medicine, supplement and healthcare product containers requiring wad sealing.

Cosmetics & Personal Care: Suitable for compatible containers used for creams, lotions, powders and other personal-care products.

Chemical & Lubricant Packaging: Can be used for selected compatible chemical, lubricant and industrial product containers.

General Packaging: Suitable for various plastic and other induction-compatible containers fitted with the correct wad liner.

How to Use

1. Prepare the Machine: Place the DGYF-600A on a stable and dry surface and connect it to a suitable 220V power supply.

2. Prepare the Container: Fill the container and fit it with the correct compatible wad-lined cap. Ensure the bottle opening, cap and sealing area are clean and dry.

3. Adjust the Settings: Set the required sealing parameters according to the container diameter, cap and wad material.

4. Position the Sealing Head: Place the handheld induction sealing head correctly over the capped container. The sealing diameter should be within the machine's 20–100 mm range.

5. Start Sealing: Activate the machine to begin the induction heating process. The electromagnetic field heats the compatible wad sealing layer.

6. Allow the Seal to Set: After completing the sealing cycle, remove the induction head and allow the container to cool briefly.

7. Inspect the Seal: Check the wad for proper adhesion and sealing quality before beginning bulk production. Adjust the settings if necessary.

Maintenance

Regular Cleaning: Keep the machine body and induction sealing head clean and free from dust, product residue and other contaminants.

Inspect the Sealing Head: Regularly check the handheld induction head and connecting cable for wear or damage.

Electrical Safety: Inspect the power cable, plug and electrical connections periodically. Do not operate the machine with damaged wiring or loose connections.

Keep the Machine Dry: Avoid exposing the machine or electrical components to water or excessive moisture.

Test Before Production: Always perform sample sealing tests whenever changing the container, cap, wad material or operating settings.

Important Notes

• This machine is suitable for compatible wad sealing only.
• Not suitable for direct aluminium foil sealing.
• The container must use a suitable induction-compatible wad/liner and cap system.
• The sealing diameter range is 20–100 mm.
• Actual production capacity depends on container diameter, wad material, sealing settings and operator handling.
• Always conduct a sample test before bulk production.
• Product videos and images should be considered for reference purposes where machine appearance or minor components may vary.

Brand: Universal Seal™

Model: DGYF-600A

Power: 500W

Sealing Diameter: 20–100 mm

Capacity: 0–65 pcs/min

Operation: Manual

Country of Origin: China

Universal Seal™ | Since 2010

Universal Packaging Solutions, New Delhi
